We already have shown you local UDP sending data using the Arduino and Sixfab Arduino NB-IoT Shield. This time we are going to repeat the same tutorial using a Raspberry Pi and Sixfab R.Pi NB-IoT shield.
All we need is a Raspberry Pi and a Sixfab R.Pi NB-IoT Shield. Plug your shield on the R.Pi and connect your DHT AM302 sensor as follow fig. Read More
Now this Evolution Board is another member of our Sixfab NB-IoT family. First of all this is not a shield, so it can be used with desired controller. For this tutorial we will be using Raspberry Pi.
Here we are trying to show how you can send data over UDP, So we need Sixfab NB-IoT EVB. Board, a Raspberry Pi and any sensor(we are using JSN-SR04T-2.0). Lets start with making our circuit connection. Pinout of the NB-IoT EVO. Board are mentioned below the board itself. Here we will need TX and RX only. Read More
Sixfab Arduino NB-IoT Shield comes with Quectel LTE BC-95 Module and a bunch of sensors. With this shield you can convert your project into an NB-IoT project.
We are going to demonstrate how to use Sixfab Arduino NB-IoT shield. In this demonstration we are going to obtain data from the light, humidity and temperature sensors.
In this tutorial we will learn how to get GPS data using 3G, 4G/LTE shield.
GPS(Global Positioning System) also known as NavStar indicates the position of an individual on the earth. The Satellites orbiting around the earth sends precise details of their positions at a regular interval of time. Once information are received by a GPS receiver, a GPS receiver can pinpoint the location.
There are also navigation systems which support in their in specific regions like GLONASS provided in Russia.
For this tutorial we will need
a. Raspberry Pi
b. 3G, 4G/LTE Shield
c. 3G, 4G/LTE module (for 3G UC20 and for 4G EC25 is used)
d. PCB Mobile Antenna (2x)
e. GPS Antenna
Here it goes
Previously we have used GPRS shield to establish internet connection. Now we will use 3G, 4G/LTE shield for PPP internet connection. In order to make a 3G and 4G connection we will need to use Quectel UC20 and Quectel EC25 modules respectively.
As this tutorial is for 4G PPP Internet connection, we will use Quectel EC25, which is a series of LTE category 4 module optimized specially for M2M, IoT and multimedia applications. Due to rich set of protocols, industry-standard interfaces and abundant functionalities extend the applicability of the module ti a wide range of M2M and IoT applications such as industrial router, industrial PDA, rugged tablet PC, video surveillance and digital signage.
