In this tutorial we will learn how to get GPS data using 3G, 4G/LTE shield.

GPS(Global Positioning System) also known as NavStar indicates the position of an individual on the earth. The Satellites orbiting around the earth sends precise details of their positions at a regular interval of time. Once information are received by a GPS receiver, a GPS receiver can pinpoint the location.

There are also navigation systems which support in their in specific regions like GLONASS provided in Russia.

For this tutorial we will need
a. Raspberry Pi
b. 3G, 4G/LTE Shield
c. 3G, 4G/LTE module (for 3G UC20 and for 4G EC25 is used)
d. PCB Mobile Antenna (2x)
e. GPS Antenna
Here it goes


1. Connect EC25 module to the shield.


Sixfab 3G,4G/LTE shield and EC25 module


EC25 module connected to shield

2. Insert SIM in the sim slot


Inserting Sim

3. Connect the shield to a Raspberry Pi


Shield attached to Raspberry Pi 3

4. Now connect antenna to the ports as shown in the figure below


Connecting Antenna

5. Now connect a microUSB to the shield from Raspberry Pi.


Tracker setup

So the setup is ready for tracking.

Now we can power our Raspberry Pi and control trough terminal as done in previous tutorials.

GPS data can be obtained either using minicom or writing your own python code.


6a. Type

minicom -s

to bring up the minicom settings screen

7Opening minicom

6b. Select Serial port setup


minicom configuration screen

6c. Make the following changes

Serial Device : /dev/ttyUSB2

Hardware Flow Control : No


Configuring Serial Port Setup

6d. Now Exit from the setting screen


Exiting from minicom configuration screen

6e. Check connectivity with ‘AT’ which in response gives ‘OK’ or returns an error.

minicom screen


minicom screen

6f. Now type ‘AT+QGPS=1’ turns on the GNSS(Global Navigation Satellite Systems) engine.


minicom screen

6g. Again go to minicom settings > Serial Port Setup and make the following changes.

Serial device : /dev/ttyUSB1

Hardware Flow Control : No


Configuring Serial Port Setup

6h. Exit from the settings screen which will bring up following screen with GPS NMEA data.


GPS Data



Now we will write a python code to obtain the GPS values

7a. First create a python file by the following command.

sudo nano


Opening .py file


7b. Now type the following python code in the file and save it. You may get the code from github.

from time import sleep
import serial

portwrite = "/dev/ttyUSB2"
port = "/dev/ttyUSB1"

def parseGPS(data):
    print "raw:", data #prints raw data
    if data[0:6] == "$GPRMC":
        sdata = data.split(",")
        if sdata[2] == 'V':
            print "no satellite data available"
        print "-----Parsing GPRMC-----"
        time = sdata[1][0:2] + ":" + sdata[1][2:4] + ":" + sdata[1][4:6]
        lat = decode(sdata[3]) #latitude
        dirLat = sdata[4]      #latitude direction N/S
        lon = decode(sdata[5]) #longitute
        dirLon = sdata[6]      #longitude direction E/W
        speed = sdata[7]       #Speed in knots
        trCourse = sdata[8]    #True course
        date = sdata[9][0:2] + "/" + sdata[9][2:4] + "/" + sdata[9][4:6]
        variation = sdata[10]  #variation
        degreeChecksum = sdata[11]
        dc = degreeChecksum.split("*")
        degree = dc[0]        #degree
        checksum = dc[1]      #checksum
        print "time : %s, latitude : %s(%s), longitude : %s(%s), speed : %s, True Course : %s, Date : %s, Magnetic Variation : %s(%s),Checksum : %s "%    (time,lat,dirLat,lon,dirLon,speed,trCourse,date,variation,degree,checksum)
        print "Printed data is ",data[0:6]
def decode(coord):
    #Converts DDDMM.MMMMM -> DD deg MM.MMMMM min
    x = coord.split(".")
    head = x[0]
    tail = x[1]
    deg = head[0:-2]
    min = head[-2:]
    return deg + " deg " + min + "." + tail + " min"

print "Connecting port"
serw = serial.Serial(portwrite, baudrate = 115200, timeout = 1)

print "Receiving GPS data"
ser = serial.Serial(port, baudrate = 115200, timeout = 0.5)
while True:
   data = ser.readline()


7c. After saving it we will run the code with following command.

sudo python


Running .py file


GPS data received

Similarly depending on the code required values from the data can be extracted.
