Sixfab 4G/LTE Cellular Modem Kit for NVIDIA Jetson Nano DevKit


·Designed for NVIDIA® Jetson Nano™ Developer Kit
·Compact design with special USB connector
·All-in-one connectivity kit
·Development friendly hardware, modification-ready
·HAT can be used via USB cables as standalone dongle


Middleware – Sixfab CORE

·Installs and handles all settings automatically on the OS and LTE modem.
·Remote terminal, configuration and support



·Global or regional coverage options
·Get a quick start on your IoT project by saving costs with the $25 data credit coupon code included in the kit.


Sixfab 4G/LTE Cellular Modem Kit for NVIDIA Jetson Nano DevKit

27 in stock


The power of modern AI

NVIDIA® Jetson Nano™ Developer Kit is an affordable & powerful computer for running multiple neural networks in parallel. The popular use cases include computer vision, AI, machine learning, image processing, object detection and speech recognition. Jetson Nano LTE Modem Kit is an add-on for the NVIDIA Jetson Nano Developer Kit. It comes with CORE support, which enables you to easily connect to the internet via 4G/LTE networks. This kit is designed to adapt your AI projects onto a networked IoT device. It’s enabling you to create machine learning models that can be connected to the internet in real-time.

Edge to Cloud, via LTE

The LTE carrier board is compatible with the NVIDIA Jetson Nano Developer Kit of both 2GB and 4GB versions. This kit is available through the Sixfab CORE platform. The CORE is designed for IoT applications in which the devices’ mobile network needs to be always available and steady. There’s no need for tricky external modem protocols or in-depth configuration. The CORE will automatically setup and take care of all the necessary settings on the operating system and 4G/LTE modem. Using Sixfab CORE’s IoT tech it can be made easier to launch your product and integrate WiFi, ethernet & cellular networks.

High-Speed IoT Modem Card Specifications

  • LTE CAT4
    • LTE-FDD: 1, 2, 3, 4, 5, 7, 8, 12, 13, 18, 19, 20, 26, 28, 66
    • LTE-TDD: 38, 40, 41
  • WCDMA: 1, 2, 3, 4, 5, 6, 8, 19
  • GSM: 850, 900, 1800, 1900 MHz
  • FDD-LTE Cat.4
    • Downlink: max. 150 Mbps,
    • Uplink: max. 50 Mbps
  • GNSS: GPS/BeiDou/GLONASS/ Galileo
  • Antenna: U.FL onboard connectors for GNSS, Main and RX-Diversity antennas
  • Region: Global
  • Regulatory: RED, GCF, CE, FCC, PTCRB, IC, UL, CCC, IFETEL, UKCA, Anatel, JATE, TELEC

Package Contents

Sixfab Jetson Nano Base HAT

  • Sixfab Base HAT
  • 40-pin GPIO stacking header
  • USB 3.0 Bridge Connector between Jetson Nano and HAT
  • M2 Screws and Standoff


Quectel EC25-G(Global) Mini PCIe 4G/LTE Module

Sixfab SIM card with $25 data credit
